Overview
The CDL10MCD is a high-performance 10W recessed LED downlight designed for modern commercial and residential applications. Compact, efficient, and stylish, it delivers excellent light quality with flexible colour options and smooth dimming control.
Key Features
-
Power & Output: 10 watts with lumen packages around 800–940 lm, depending on colour temperature.
-
Selectable Colour Temperatures: Choose from 2700K, 4000K, or 5700K using an easy rear dip-switch.
-
Beam Angle: Wide 90° beam for uniform light distribution.
-
Dimmable: Triac dimming from approximately 8%–100% for full control of ambiance.
-
Compact Size: 115 mm diameter, 61 mm depth, with a cut-out of 90–95 mm.
-
High Colour Rendering: CRI >80 for natural and accurate light quality.
-
Durability: IP54 protection, fire-proof to 94-VO, and suitable for damp locations.
-
Long Life: Rated to 40,000 hours with a 2-year manufacturer warranty.
Applications
-
Retail and showrooms
-
Commercial offices
-
Restaurants and hospitality
-
Residential living spaces and renovations
Quick Specs
| Specification | Details |
|---|---|
| Power | 10W |
| Lumens | ~800–940 lm |
| CCT Options | 2700K / 4000K / 5700K |
| CRI | >80 |
| Beam Angle | 90° |
| Cut-Out Size | 90–95 mm |
| Diameter | 115 mm |
| Depth | 61 mm |
| Dimming | Triac, 8–100% |
| IP Rating | IP54 |
| Lifespan | ~40,000 hours |
| Warranty | 2 Years |
